5MP Analog HD Camera (US/EU Only)
5MP Analog HD Camera (US/EU Only)
5MP Analog HD Smart Light Bullet Security Camera Only
(3K, 2.8mm, IP67) — (US/EU Only)
Get clearer, brighter monitoring day or night with a 5MP Analog HD bullet security camera built for indoor/outdoor use. It records in 3K resolution (2960 × 1665) with a wide 2.8mm lens, and uses smart night lighting that runs IR normally—then switches to white light when a human or vehicle is detected. It also includes a built-in microphone for audio over coaxial cable.
Why I Chose This
If I’m running an Analog HD (BNC) DVR setup, the biggest pain is usually compatibility and night visibility. I chose this model because it’s explicit about DVR requirements, offers switchable output modes, and gives you the best of both worlds at night: discreet IR plus bright white light when there’s a person or vehicle.
Compatibility (Important)
This camera ONLY works with DVR models: DW81KD-V6 DW61LD-V6 It does NOT support third-party DVR systems. This is an Analog HD (BNC) camera — not an IP/WiFi camera.
Size Specifications
- Resolution: 3K / 5MP (2960 × 1665, 16:9)
- Lens: 2.8mm fixed focal, F1.2
- Field of View: 107° (H) / 64° (V) / 129° (D)
- Dimensions: 138.8 × 60.9 × 57.9 mm (5.47" × 2.40" × 2.30")
- Weight: ~155 g (0.34 lb)
- Housing: Plastic
- Color: White
Key Features
- 3K / 5MP Imaging — High-detail video at 2960 × 1665 for sharper monitoring
- Smart Night Visibility (IR + White Light) — IR range up to 25 m; White light range up to 20 m; At night, IR runs normally and switches to white light when a human or vehicle is detected
- Built-In Microphone (Audio Over Coax) — Captures audio via coaxial cable setup (built-in mic)
- Switchable Video Output Signals (One Port) — BNC output with TVI / AHD / CVI / CVBS switchable support
- Weatherproof For Outdoor Use — IP67 water & dust resistant; Operating temperature -40°F to 140°F (-40°C to 60°C)
- Low-Light Performance — Min illumination 0.01 Lux (color, F1.2, AGC on); 0 Lux with IR
- Frame Rate / Signal Support — TVI 3K @ 20 fps; 4MP @ 25/30 fps; 1080p @ 25/30 fps; AHD 5MP @ 20 fps; 4MP @ 25/30 fps; CVI 4MP @ 25/30 fps; CVBS PAL/NTSC
- Power — 12 VDC +/- 25%; Max consumption 2.9 W
What’s Included
- 1 × 5MP Analog HD bullet camera (smart light, built-in mic)
Estimated Shipping
- Processing Time: 1–2 business days
- Estimated Delivery: 3–10 business days (US/EU Only)
- Free Shipping: On all orders $35+
- Tracking: Provided with every order
FAQ
Will This Work With My Existing DVR? Only if your DVR model is DW81KD-V6 or DW61LD-V6. It’s not compatible with third-party DVRs.
Is This A WiFi / App Camera? No—this is an Analog HD (BNC) camera.
What’s The Benefit Of Smart White Light? You get discreet IR most of the time, then brighter color/visibility when there’s a person or vehicle detected—useful for driveways and entryways.
